Work in progress

NCGen is getting a new tool set for easy wing design.

This feature will greatly help out users who want quick, accurate, tapered wing designs to be hot wire cut on both our FC6A as well as other hotwire machines!

Wing Generator!

Wing Generator!

NCGen now does pocket milling

NCGen is now capable of some simple pocket milling.  This greatly speeds up the process in making pocket cuts that start in the center of the cut and work their way into the stock material.  This feature will be very handy in making servo pockets, landing gear cut outs, and battery bays in flying wings! A basic 'how to' on using the pocket generator tool on a grouped face to create pocket mill tool paths in Sketchup.

Recommended SketchUp Plugins/Extensions

SketchUp News

SketchUp News

Here is a list of plugins / extensions that I use for deigning my models in SketchUp, best of all most of these be found for free on the internet and most are provide as open source.  Many of the authors have graciously provided these plugins for free, although most accept donations for their incredible work.  I have attempted to link to these extensions, however most of them are continuously updated through the webpage or through the built in Sketchup Extension Manager, so if you happen across a dead link please let me know in the comments below.

(see Sketchup RBZ file support here for what to do with rbz files)

Foam Casualty Airfoil Data Loader (This is now obsolete, an updated and improved airfoil data loader is included with NCGen)

FreeDXF by Jim Foltz which likely allows a better DXF import over the Pro version of SU.
(also read this, DXF )

Mirror Selection by TIG

Find Stray Lines by Smastard (used in assistance of 3d tool path creation)

The Unfold Tool by Jim Foltz

Vertex Tools by  Thomas Thomassen.

Fredo Collection including:
Tools On Surface
Fredo Tools
and don't forget the requiredFredo Shared Library for his plugins used by the Fredo Collection.

And of course we can't forget the Foam Casualty NCGen extension.

NCGen Features

2D / 2.5D / 3D cut paths (faces and lines):

2d Hotwire cut paths:

3d tapered Hotwire cut paths (Wing Design with help of some of the above listed plugins):

3D Cut Paths (surfaces) and Pocket Milling: A basic 'how to' on using the pocket generator tool on a grouped face to create pocket mill tool paths in Sketchup.

NC Gen is included with all machine sales and updates are provided as they become available.

Launching Foam Casualty's New Site

Unfortunately, our old site has been hacked and we are forced to go ahead and launch the new before everything has been moved over.  Thank you for your patience while we make this transition.  As always, if you have any questions for us please do not hesitate to ask!  Go ahead and visit our Contact Page to get in touch with us.
